2011 FQ-R Series Computer Control Hot-sealing and Hot-cutting Bag Making Machine

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: FQ-R

Production Capacity: 300sets/year

Delivery Date: 30Days

Automatic Grade: Automatic

Usage: Outer

Brand Name: MTED

Means of Transport: Ocean

Packing: with wooden case

Processing: Packing Machine

Type: General

Packaging: Plastic

style: hot-sealing and hot-cutting

1>Micro-computer control
2>Intelligent temperature control
3>Speed of Bag Making:30-160pcs/min

Use:

This machine is suitable for hot-sealing and hot-cutting HDPE\LDPE and plastic film.And It's an ideal facility for producting original color and multicolor T-shirt bag.

Function:

1\Computer control automatic in-phase sealing\hot-cutting; deep-set bottom sealing\beautiful.

2\Micro-computer control\step motor feeding-material\feeding fitly\even tension\automatic temperature control.

3\Freely set length\freely definite number\Auto meter counting\Alarm when complete.

4\Photoelectric tracking\balanced precision\Auto stop when losing mark.

5\direct current motor adjusting speed;It have auto protect function when over loading\over current and over voltage.

6\The sealing and cutting blade design properly\easy to cleaning and exchange rubberized fabric.

7\Adopt photoelectric tracking choke material\Auto stop when choke material or no material come out.

Main Technical Parameters:

Model
600
700
Max.Length of Making Bag(mm)
700
700
Mas.Width of Making Bag(mm)
550
650
Bag-Making Speed (pcs/min)
30-150
30-150
Sealing and Cutting Thickness(um)
0.02~~0.15
0.02~~0.15
Power Supply(V)
220/380
220/380
Total Power(kw)
3.0
4.5
Machine Weight(kg)
450
550
Machine Dimension(mm)
2900x1350x1650
2900x1450x1650
Incasement Weight(kg)
550
600
