2011 FQ-C Series Computer Control Double-layer Hot-sealing and Cool-cutting Bag Making Machine

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: FQ-C

Production Capacity: 300sets/year

Delivery Date: 30Days

Automatic Grade: Automatic

Usage: Outer

Brand Name: MTED

Means of Transport: Ocean

Packing: with wooden case

Processing: Packing Machine

Type: General

Packaging: Plastic

use: Auto punching with U shape

1>Micro-computer control
2>Intelligent temperature control
3>Speed of Bag Making:30-160pcs/min

Use:

This machine is suitable for sealing and cutting high density polyethylene(HDPE)\low density polyethylene (LDPE)\polypropylene(PP)and plastic film.And It's an ideal facility for producting flat bag and T-shirt bag.

Function

1.This machine adopt micro-computer control,Step motor material-feeding(can be chosen import servo motor system material-feeding).Feeding double-layer\one-off molding by U shape punching,easy to operate,high efficiency to manufacture.

2.Micro-computer freely set length,photoelectric printing and Auto tracking\Precision,Auto stop when lose mark,material-feeding adopt photoelectric controller.

3. Auto meter counting and freely set alarm.

4. Automatic constant temperature control makes bag mouth deep-set sealing and fitly.

Main Technical Parameters:

Model	600	700	800
Max.Length of Making Bag(mm)	300-600	300-600	300-600
Mas.Width of Making Bag(mm)	150-260	150-300	200-350
Sealing and Cutting Thickness(um)	0.015-0.04	0.015-0.04	0.015-0.04
Bag-Making Speed (pcs/min)	(30-100) x 4	(30-100) x 4	(30-100) x 4
Power Supply(V)	220V	220V	220V
Total Power(kw)	5.5	6.5	8.0
Machine Weight(kg)	1200	1300	1400
Machine Dimension(mm)	5400x1100x1800	5400x1200x1800	5400x1300x1800
Incasement Weight(kg)	1400	1500	1600
