2011 FQ-B Series Computer Control Doule-layer Hot-sealing and Cool-cutting Bag Making machine

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: FQ-B

Production Capacity: 300sets/year

Delivery Date: 30Days

Automatic Grade: Automatic

Usage: Inner

Brand Name: MTED

Means of Transport: Ocean

Packing: with wooden case

Processing: Packing Machine

Type: General

Packaging: Plastic

style: double-layer

1>Micro-computer control
2>Total Power:4.3kw,4.5kw,4.8kw,5.7kw
3>Speed of Bag Making:30-140pcs/min

Use:

This machine is suitable for sealing and cutting high density polyethylene(HDPE)\low density polyethylene (LDPE)\polypropylene(PP)and plastic film. And It's an ideal facility for producing shopping bag\market bag\ flat bag and T-shirt bag.

Function:

1.This machine adopt micro-computer control,Step motor material-feeding(can be chosen import servo motor system material-feeding).

2.Micro-computer freely set length,photoelectric printing and Auto tracking,Precision,Auto stop when lose mark,material-feeding adopt photoelectric controller.

3. Auto meter counting and set alarm Freely.

4. Automatic constant temperature control makes bag mouth deep-set sealing and fitly.

Main Technical Parameters:

Model	600	700	800	1000	1300
Max.Length of Making bag(mm)	1500	1500	1500	1700	1700
Mas.Width of Making Bag(mm)	550	550	550	1250	1250
Sealing and Cutting Thickness(um)	0.015-0.04	0.015-0.04	0.015-0.04	0.015-0.04	0.015-0.04
Bag-Making Speed (pcs/min)	(30-160) x 2/ x 4	(30-160) x 2/ x 4	(30-160) x 2/ x 4	(30-130) x 2	(30-130) x 2
Power Supply(V)	220V	220V	220V	380V	380V
Total Power(kw)	4.0	5.0	6.0	7.5	9.5
Machine Weight(kg)	700	750	800	900	1000
Machine Dimension(mm)	3200x1100x1800	3200x1200x1800	3200x1300x1800	3200x1500x1800	3300x1300x1800
Incasement Weight(kg)	750	850	850	950	1100
