2011 QFJ-IV Automatic Computer Control Slitting and Cutting Machine

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: QFJ-IV

Production Capacity: 500sets/year

Delivery Date: 30Days

Certification: CE

Brand Name: MTED

Means of Transport: Ocean

Packing: standard wooden case

Product Type: Paper Bag Making Machine

Processing Type: Paper Slitting and Rewindin...

function: slitting and rewinding

1.Total power:11kw
2.The speed of machine:16-160m/min
3.The feature of machine is stability, secunlty, efficient, etc.

Use:

The machine is suitable for self-adhesive paper,kraft paper and other kinds of paper.

Function:

1 Unwinding device adopt auto air-cylinder full automatic lift type

2 Rewinding up and down double shafts. Unwinding and rewinding adopts magnetic powder tension control.

3 The main motor adopts stepless speed regulation,Auto photoelectric edge corrector or hydraulic pressure can be chosen,and the other functions, such as meter presetting and auto stoppage, and so on.

Main Technical Parameters:

Model	1300-Model	1600-Model	1800- Model
Max.Width of Raw Material(mm)	1300	1600	1800
Max.Diameter of Raw Material (mm)	1300	1300	1300
Max.Diameter of Rewinding(mm)	800	800	800
Speed of Machine(pcs/min)	20-200	20-200	20-200
Power Supply(V)	380V (three-phase four-wire power cable)	380V(three-phase four-wire power cable)	380V(three-phase four-wire power cable)
Total Power(kw)	9.5	11	15
Machine Weight(kg)	2500	3000	3500
Incasement Weight(kg)	3100	3500	40000
Machine Dimension(mm)	2500x2700x1800	2800x3000x1800	3000x3200x1800
