QFJZ-1100/1800 Series Micro-computer Control Paper Slitting Machine
| Price: | 15800.0~18000.0 USD |
| Payment Terms: | T/T,L/C |
| Place of Origin: | Zhejiang, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
1.The main motor adopts the frequency inverter control
2.Auto tension device
3.Edge correction device (EPC)
CHARACTERISTICS
1. The machine is mainly used to slit stick paper, craft paper and other kinds of paper
2. Entire machine is controlled by PLC(two vector motors), man-machine interface, screen touch operation
3. Unwinding part adopts Italy RE pneumatic brake control, the rolling diameter is automatically calculated by PLC, to achieve constant tension control.
4. Traction control is driven by a vector variable frequency motor, to achieve constant linear velocity control, and effectively cut off interactant tension between rewind and unwind
5. Rewinding part uses the vector frequency conversion motor, to drive magnetic powder clutch, realized by the PLC automatic cliameter counting auto tension control.
6. Unwinding parts adopts hydraulic power feed, which can save much labour force and shorten time.
7. Auto meter presetting, EPC error correction device is positive to assure the accuracy.
1. The machine is mainly used to slit stick paper, craft paper and other kinds of paper
2. Entire machine is controlled by PLC(two vector motors), man-machine interface, screen touch operation
3. Unwinding part adopts Italy RE pneumatic brake control, the rolling diameter is automatically calculated by PLC, to achieve constant tension control.
4. Traction control is driven by a vector variable frequency motor, to achieve constant linear velocity control, and effectively cut off interactant tension between rewind and unwind
5. Rewinding part uses the vector frequency conversion motor, to drive magnetic powder clutch, realized by the PLC automatic cliameter counting auto tension control.
6. Unwinding parts adopts hydraulic power feed, which can save much labour force and shorten time.
7. Auto meter presetting, EPC error correction device is positive to assure the accuracy.
technical parmeter:
Model | QFJZ-1100/1800 |
Max.Range of material | 1100-1800(mm) |
Max.Slitting Speed | 140(m/min) |
Max.Diameter of Rewinding | 800(mm)special design |
Max.Diameter of Winding | 1000(mm)special design |
Total Motor Power | 5(kw) |
Weight | 3000(kgs) |
Overall Simension | 2250×2500×2250(mm) |
