2011 WZDJ-A Full Automatic Multifunction Non Woven Fabric Bag Making Machine WZDJ-A manufacturer from China Wenzhou Ruizhi packing machinery co.LTD

2011 WZDJ-A Full Automatic Multifunction Non Woven Fabric Bag Making Machine

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: WZDJ-A

Production Capacity: 300sets/year

Delivery Date: 45Days

Automatic Grade: Automatic

Usage: Outer

Brand Name: MTED

Means of Transport: Ocean

Packing: standard wooden pallet

Processing: Packing Machine

Type: General

Packaging: Others

material: non-woven fabric

1.produce kinds of non-woven bags( flat ,box ,shopping,t-shirt bags)
2.high quality and reasonable price
3.fast after service

Use:

This machine continual improved by our company, according to same industry technical norms of the most advanced in the world at present,recast and designed by the newest demic engineering. Multi-function\fast speed\quality stable. Now, this machine become the newest generation full automatic multifunction non woven fabric bag making machine, and this equipment use non-woven fabric raw material,can made various type bag\different type non-woven fabric bag,such as gift bag\handle bag\flat bag\T-shirt bag etc. It have superiority to make many kinds of bag on the machine,get more favor and good opinion from native and foreign customers! Completely attain CE safety standards in Europe.

Function:

1. This machine adopt Taiwan touch screen computer display,PLC computer program which can edit.

2. Auto meter counting,stopping could freely setting number.

3. Computer Fixed-length,printing color mark track orientation,Auto-stop when complete.

4. high voltage static processor,Auto constant temperature heating controller.

5 It could control auto pneumatic handle punch\vest bag waste material blower remove waste\T-shirt bag automatic contact punch.

6. Unwinding magnetic powder tension control with manual,Auto side-correction control.

7.This machine adopt ultrasonic welding of all aspects,bag mouth folding welding,bottom sealing,side sealing,once full completed,fast speed\east to operate\firm sealing,beautiful and decent.

Main Technical Parameters:

600 Modle
Bag Type	Flat bag	Rope bag	T-shirt bag
Length of bag( mm)	100-800	300-600	300-800
Width of bag( mm)	300-550	350-550	150-360
Speed of bag( pcs/min)	20-110	20-100	20-70
Material thickness ( g)	35-100	25-100	35-60
Inserting size( mm)	30-90	45-80	40-120
Power Supply(V)	380	380	380
Total Power(kw)	11	11	13
Machine Weight(kg)	3000	3000	3000
Incasement Weight(kg)	3500	3500	3500
Machine Dimension L shape(mm)	5100x1100x1600 4000x1600x1600

700 Model
Bag Type	Flat bag	Rope bag	T-shirt bag
Length of bag( mm)	100-800	300-600	300-800
Width of bag( mm)	300-650	350-550	150-420
Speed of bag( pcs/min)	20-110	20-100	20-70
Material thickness ( g)	35-100	25-100	35-60
Inserting size( mm)	30-90	45-80	40-120
Auto manipulator nip bag (pcs/min)	1-15	1-15	1-15
Power Supply(V)	380(Three-phase Four-wire power cable)
Total Power(kw)	14
Machine Weight(kg)	3200
Incasement Weight(kg)	3700
Machine Dimension L shape(mm)	5100x1300x1800 4000x1800x1800

800 Model
Bag Type		Flat Bag	T-shirt Bag
Length of Bag (mm)		100-700	300-600
Width of Bag (mm)		300-750	200-480
Speed (pcs/min)		20-110	20-70
Material Thickness (g)		35-100	35-65
Inserting Size (mm)		40-90	40-120
Machine Power		380v (Three-phase Four-wire power cable)
Air Pressure
Total Power(kw)		15
Machine Weight(kg)		3500
Incasement Weight(kg)		4000
Overall Dimension L Shape (mm)		6800x1300x1800 4000x2000x1900
With T-shirt bag punch(pcs)	5-10pcs
Dimension with T-shirt bag punch(mm)	2800x1200x1900
